Grove - EL Driver [Discontinued]
Grove - EL Driver is designed for driving EL Wires.It integrates a very small inverter to drive the EL Wire, so you can easily light up the EL Wire with just one single Grove cable.
Features:
- Grove compatible interface
- 3.3V/5V Compatible
- Integrated Inverter Transformer
- Product number: Seeed 105020005
Specifications:
- Input Current: 300mA Max (According to the load)
- Input Voltage 3~5Vdc
- Output Voltage:70~110Vpp
- Output frequency: 8~20kHz
- Supported max EL Capacitance: 15nF
Resources
Grove - EL Driver is designed for driving EL Wires.It integrates a very small inverter to drive the EL Wire, so you can easily light up the EL Wire with just one single Grove cable.
Features:
- Grove compatible interface
- 3.3V/5V Compatible
- Integrated Inverter Transformer
- Product number: Seeed 105020005
Specifications:
- Input Current: 300mA Max (According to the load)
- Input Voltage 3~5Vdc
- Output Voltage:70~110Vpp
- Output frequency: 8~20kHz
- Supported max EL Capacitance: 15nF
Resources
$3.32
Original: $9.50
-65%Grove - EL Driver [Discontinued]—
$9.50
$3.32Description
Grove - EL Driver is designed for driving EL Wires.It integrates a very small inverter to drive the EL Wire, so you can easily light up the EL Wire with just one single Grove cable.
Features:
- Grove compatible interface
- 3.3V/5V Compatible
- Integrated Inverter Transformer
- Product number: Seeed 105020005
Specifications:
- Input Current: 300mA Max (According to the load)
- Input Voltage 3~5Vdc
- Output Voltage:70~110Vpp
- Output frequency: 8~20kHz
- Supported max EL Capacitance: 15nF
